Chevrolet TrailBlazer I (2001-2006) backup fuse 27 sir fuse 18 Wiring diagram
This page shows the only wiring diagram for the component.backup fuse 27 sir fuse 18, which is found in the car Chevrolet TrailBlazer I (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup fuse 27 sir fuse 18 (1 of 1)
4.2L
5.3L
AIR SOL FUSE 54
AIR SOL RELAY
AUTOMATIC TRANSMISSION SHIFT LEVER STOP LAMP SWITCH
BACKUP FUSE 27 SIR FUSE 18
BLK WIRE
BODY CONTROL MODULE (BCM)
BTSI FUSE 25
CANISTER VENT FUSE 15
COILS FUSE 14
DK GRN WIRE
EAP RELAY 49
ENG 1 FUSE 26
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID
F/PMP RELAY 41
FAN FUSE 20
FAN RELAY 45
FROM FLASH FUSE 52 (DIAGRAM 2 OF 7)
FROM IGNITION SWITCH (DIAGRAM 2 OF 7)
FROM PCM I FUSE 28
FUEL INJECTOR 1 FUEL INJECTOR 3 FUEL INJECTOR 2
FUEL INJECTOR 5 FUEL INJECTOR 4
FUEL INJECTOR 6
FUSE 29 (DIAGRAM 3 OF 7)
GRY WIRE
HDLP-HI RELAY 43
HEADLAMP DRIVER MODULE (HDM) RELAY 46
HEADLIGHTS SYSTEM
IGNITION COIL 1
IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4
IGNITION COIL 6 IGNITION COIL 5
INFLATABLE RESTRAINT SENSING AND DIAGNOSTIC MODULE (SDM)
LEFT HEADLAMP
LT GRN WIRE
LT HI HDLP FUSE 5
LT LOW HDLP FUSE 6
NCA WIRE
ORG/ WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH
PCM B FUSE 10
PCM I FUSE 28
PNK PNK PNK PNK WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
RIGHT HEADLAMP
RT HI HDLP FUSE 2
RT LOW HDLP FUSE 3
SECONDARY AIR INJECTOR DUMP RELAY
SENSOR 1 SENSOR 2
TAC FUSE 23 FUSE 29 (4.2L) (4.2L)
TAN WIRE
TBC 1 FUSE 31
THEFT DETERRENT ALARM (IF EQUIPPED)
TO IGNITION RELAY 58 (DIAGRAM 6 OF 7)
TRAILER CONNECTOR
TRLR B/U FUSE 4
UNDER- HOOD FUSE BLOCK
UNDER- HOOD FUSE BLOCK IGN E FUSE 22 (DIAGRAM 4 OF 7)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 7) -> BACKUP FUSE 27 SIR FUSE 18
