Chevrolet TrailBlazer I (2001-2006) audio common Wiring diagram
This page shows the only wiring diagram for the component.audio common, which is found in the car Chevrolet TrailBlazer I (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio common (1 of 1)
AUDIO COMMON
B(+)
BARE
BARE DRAIN WIRE
BLK WIRE
BLK/WHT WIRE
BRN/WHT WIRE
CL 2 SER DATA
COMPUTER DATA LINES SYSTEM
DELETE
DIGITAL RADIO RECEIVER
DIGITAL VIDEO DISK (DVD) PLAYER
DK GRN/WHT WIRE
GROUND
HOT AT ALL TIMES
L AUDIO SIG (+)
LOGIC
OH BATT/ ONSTAR FUSE 27
ORG/ WIRE
PLAY
R AUDIO SIG (+)
RADIO
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
REC
VOICE RECORDER
YEL/BLK WIRE
Go to component -> Dvd player/voice recorder circuit -> AUDIO COMMON
