Chevrolet TrailBlazer I (2001-2006) (5 cm from main harn, breakout for Wiring diagram
This page shows the only wiring diagram for the component.(5 cm from main harn, breakout for, which is found in the car Chevrolet TrailBlazer I (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (5 cm from main harn, breakout for (1 of 1)
5.3L
5.3L 5.3L
A/C COMPRESSOR CLUTCH ASSEMBLY
BARE
BLK WIRE
BRAKE FLUID LEVEL SWITCH
EAP RELAY 49
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
F/PUMP RELAY 41
FAN RELAY 45
FRONT AXLE ACTUATOR (IF EQUIPPED)
FRONT PASSENGER DOOR MODULE (FPDM)
HDM RELAY 46
IGNITION 1 RELAY 58
INTAKE AIR TEMPERATURE (IAT)/MASS AIR FLOW (MAF) SENSOR
LEFT CORNERING LAMP (IF EQUIPPED)
LEFT FRONT FOG LAMP
LEFT FRONT MARKER LAMP
LEFT FRONT PARK LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP
LEFT HEADLAMP LEVELING ACTUATOR (IF EQUIPPED)
NCA WIRE
ONSTAR MICROPHONE GROUND SHIELD 2
PARK/ NEUTRAL POSITION (PNP) SWITCH
PASSENGER SEAT ADJUSTER SWITCH PASSENGER LUMBAR ADJUSTER SWITCH
POWERTRAIN CONTROL MODULE (PCM)
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR WINDOW SWITCH
SECONDARY AIR INJECTION (AIR) SOLENOID
THROTTLE ACTUATOR CONTROL (TAC) MODULE
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENG COMPT)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
W/ POWER ADJUSTABLE PEDAL
W/ VEHICLE COMMUNICATION SYSTEM
W/ WIRING PROVISIONS
Go to component -> Ground distribution circuit (4 of 6) -> (5 CM FROM MAIN HARN, BREAKOUT FOR
