Chevrolet TrailBlazer I (2001-2006) 17 4 serial data latch relay Wiring diagram

17 4 SERIAL DATA LATCH RELAY 6 8 2 UNLOCK CTRL LOCK CTRL SERIAL DATA BATT GROUND BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BENEATH LEFT REAR SEAT) BRN WIRE DDM FUSE 10 DK BLU/WHT WIRE DK GRN WIRE DRIVER DOOR JAMB SWITCH DRIVER DOOR LOCK ACTUATOR DRIVER DOOR LOCK SWITCH DRIVER DOOR MODULE (BELOW DRIVER DOOR SWITCH PANEL) ENDGATE MODULE FRONT PASSENGER DOOR JAMB SWITCH FRONT PASSENGER DOOR LOCK ACTUATOR FRONT PASSENGER DOOR MODULE (BELOW FRONT PASS DOOR SWITCH PANEL) GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES LEFT REAR DOOR JAMB SWITCH LEFT REAR DOOR LOCK ACTUATOR LIFTGATE DOOR LOCK ACTUATOR LIFTGATE MODULE LOCK LOCK CTRL LOCK RELAY 18 LOCKS FUSE 21 LOW REF DOOR AJAR LR DOOR AJAR RR DOOR AJAR LT BLU WIRE LT BLU/BLK WIRE LT DOORS CB 2 LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE PASSENGER DOOR LOCK SWITCH PDM FUSE 12 RT DOORS CB 1 POWER REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RIGHT REAR DOOR JAMB SWITCH RIGHT REAR DOOR LOCK ACTUATOR SERIAL DATA TAN WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM UNLOCK UNLOCK CTRL UNLOCK RELAY 24 UNLOCK RELAY LOCK RELAY WHT WIRE YEL WIRE
