Chevrolet Tracker III (2013-2017) passenger window switch logic Wiring diagram
This page shows the only wiring diagram for the component.passenger window switch logic, which is found in the car Chevrolet Tracker III (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger window switch logic (1 of 1)
BCM 1 FUSE
BCM 4 FUSE
BCM 5 FUSE
BCM 6 FUSE
BCM 7 FUSE
BLK WIRE
CHEVROLET BUICK
COMPUTER DATA LINES SYSTEM
DLIS FUSE
GRN WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT PANEL FUSE BLOCK
LEFT STEERING WHEEL CONTROLS SWITCH
LIFTGATE LATCH
MTR STATUS
NETWORK BUS 3
OFF
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER WINDOW SWITCH LOGIC
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RF DR AJAR SW SIG
RIGHT STEERING WHEEL CONTROLS SWITCH
RUN WIRE
STEERING WHEEL AIR BAG COIL
VIO/BLK WIRE
VIO/GRY WIRE
W/ CRUISE CONTROL
WHT WIRE
WHT/BRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Interior lights circuit (2 of 4) -> PASSENGER WINDOW SWITCH LOGIC
