Chevrolet Tracker III (2013-2017) hood open sw sig Wiring diagram
This page shows the only wiring diagram for the component.hood open sw sig, which is found in the car Chevrolet Tracker III (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hood open sw sig (1 of 1)
BATT POSITIVE VOLT
BCM 1 FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE
GMLAN SERIAL DATA
GRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY/BLK WIRE
HI SPD GMLAN (-) 1
HOOD AJAR SW SIG
HOOD AJAR SWITCH
HOOD OPEN SW SIG
HOT AT ALL TIMES
IMMOBILIZER CONTROL MODULE
IMMOBILIZER CTRL
IMMOBILIZER LOW REF
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LO SPD GMLAN
LO SPD SERIAL DATA
LOGIC
NETWORK BUS 11
RED/GRN WIRE
SECURITY INDICATOR
SIG GND
SW SIG
WHT WIRE
YEL WIRE
Go to component -> Pass-key circuit -> HOOD OPEN SW SIG
