Chevrolet Tracker III (2013-2017) coolant temp sens low reference Wiring diagram
This page shows the only wiring diagram for the component.coolant temp sens low reference, which is found in the car Chevrolet Tracker III (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coolant temp sens low reference (1 of 1)
BAT +VE VOLT
BLK WIRE
BLK/BRN WIRE
BLK/LT BLU WIRE
BLU WIRE
BRN/YEL WIRE
CANISTER PURGE SOL, WATER VALVE SOL, TURBO WASTEGATE SOL, TURBO BYPASS SOL FUSE
COMPUTER DATA LINES SYSTEM
COOL FAN HIGH FUSE
COOL FAN LOW/MID FUSE
COOLANT TEMP SENS 2 LOW REFERENCE
COOLANT TEMP SENS LOW REFERENCE
COOLANT TEMP SENSOR SIG
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN MEDIUM SPEED RELAY
COOLING FAN MOTOR
COOLING FAN RELAY
COOLING FAN RESISTOR (LOWER LEFT SIDE OF DASH)
COOLING FAN SPEED CONTROL RELAY
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE
ENGINE COOLANT RADIATOR TEMPERATURE SENSOR
ENGINE COOLANT TEMP SENS SIG
ENGINE COOLANT TEMPERATURE IND
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT THERMOSTAT HEATER
FAN RLY (AUX BEC) FUSE
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HI SPEED COOLING FAN RLY CTRL
HIGH SPEED GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
IPC B+ FUSE
LO SPEED COOLING FAN RLY CTRL
LOGIC
LOW SPEED GMLAN SERIAL DATA
LT BLU WIRE
LT GRN/VIO WIRE
RED WIRE
RED/BLU WIRE
THERMOSTAT ENG COOL CTRL
UNDERHOOD FUSE BLOCK
UNDERHOOD RELAY BLOCK
VIO/BLU WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> COOLANT TEMP SENS LOW REFERENCE
