Ground distribution circuit for Chevrolet Tracker II (1998-2004)

1.6L, 2.0L 2.0L ONLY 2.5L ONLY 28 9 17 26 6 25 (1.6L/2.0L) (2.5L) A/C COMPRESSOR CONTROL MODULE A/C CONDENSER FAN A/C REFRIGERANT PRESSURE SWITCH BATTERY BLK WIRE BLK/GRY WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH CRUISE CONTROL SERVO FRONT DRIVE AXLE ACTUATOR PUMP FRONT WASHER PUMP FRONT WIPER MOTOR FUEL SENDER ASSEMBLY GRN WIRE HEATED OXYGEN SENSOR 2 SHIELD HORN IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 INSTRUMENT CLUSTER KNOCK SENSOR (KS) SHIELD LAMP LEFT FRONT SIDE MARKER LEFT FRONT TURN SIGNAL NCA WIRE ORG/ WIRE OXYGEN HEATER RELAY POWERTRAIN CONTROL MODULE (PCM) REAR WASHER PUMP RIGHT FRONT SIDE MARKER RIGHT FRONT TURN SIGNAL SHIFT LOCK RELAY VEHICLE SPEED SENSOR W/ A/T W/ CRUISE CONTROL YEL WIRE

4 DOOR W/ POWER WINDOWS ONLY AMBIENT LIGHT SENSOR AUXILIARY POWER OUTLET BLK WIRE BLOWER MOTOR RELAY CIGAR LIGHTER CRUISE CONTROL DATA LINK CONNECTOR (DLC) DIMMER SWITCH DOME LAMP DRL CONTROL MODULE CRUISE CONTROL RELEASE SWITCH ELECTRONIC BRAKE CONTROL MODULE (EBCM) FOUR WHEEL DRIVE LOW SWITCH FOUR WHEEL DRIVE SWITCH HEADLAMP IGNITION SWITCH INSTRUMENT CLUSTER INSTRUMENT CLUSTER LAMP DIMMER CONTROL JUNCTION BLOCK LIGHT SWITCH MAP LAMP MASTER WINDOW SWITCH NCA WIRE NOISE SUPPRESSOR FILTER RADIO REAR DEFOGGER RELAY REAR DEFOGGER SWITCH RED/BLK WIRE REMOTE CONTROL MIRROR SWITCH TURN SIGNAL/ HEADLAMP SWITCH TURN/ HAZARD FLASHER W/ A/T W/ ABS W/ M/T WHT WIRE WIPER/ WASHER SWITCH

2 DOOR ONLY BLK WIRE BLOWER SWITCH CENTER HIGH MOUNTED STOPLAMP (CHMSL) DOME LAMP DOOR LOCK RELAY DOOR UNLOCK RELAY FUEL SENDER ASSEMBLY INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) LEFT TAILLAMP LICENSE PLATE LAMP OVERDRIVE SWITCH REAR DEFOGGER REMOTE CONTROL DOOR LOCK RECEIVER SEAT BELT SWITCH RIGHT TAILLAMP SHIFT LOCK DIODE SHIFT LOCK SOLENOID SHIFT PROGRAM SWITCH SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) DATA LINK CONNECTOR (DLC) (NOT USED) TRAILER HARNESS W/ A/T WHT WIRE
