Chevrolet Tracker II (1998-2004) temperature gauge Wiring diagram
This page shows the only wiring diagram for the component.temperature gauge, which is found in the car Chevrolet Tracker II (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram temperature gauge (1 of 1)
ABS CIRCUIT
ABS IND.
AIR BAG IND
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR)
BRAKE IND
BRN WIRE
CHARGE IND
CRUISE CONTROL SYSTEM
CRUISE IND
DAYTIME RUNNING LAMPS (DRL) CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
DOME FUSE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE)
EXTERIOR LIGHTS SYSTEM ENGINE CONTROLS SYSTEM
FUEL GAUGE
FUEL LEVEL SENSOR
FUEL SENDER ASSEMBLY (MOUNTED ON TOP OF FUEL TANK)
GRN/RED WIRE
GRN/YEL WIRE
GRY (OR BLK) WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEADLIGHTS SYSTEM
HI-BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
IG FUSE
IGNITION SWITCH
INSTRUMENT CLUSTER
JUNCTION BLOCK
LEFT TURN IND
LOCK
MULTI- FUNCTION ALARM
O/D OFF IND
OIL IND
ORG/BLK WIRE
PARK BRAKE SWITCH
POWER IND
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF DASH)
PPL
PPL/RED WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT TURN IND
RUN WIRE
SEAT BELT IND
SERVICE ENGINE SOON IND
SPEEDOMETER
STARTING/CHARGING SYSTEM WARNING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TEMPERATURE GAUGE
TRANSMISSION SYSTEM ANTI-LOCK BRAKE SYSTEM
TRANSMISSION SYSTEM INTERIOR LIGHTS SYSTEM
TRANSMISSIONS, ANTI-LOCK BRAKE SYSTEMS
WARNING SYSTEM
WARNING SYSTEM INTERIOR LIGHTS SYSTEM
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Instrument cluster circuit -> TEMPERATURE GAUGE
