Chevrolet Tracker II (1998-2004) shift lock relay Wiring diagrams
This page contains all the electrical diagrams for the component. shift lock relay, in which he is found in the car Chevrolet Tracker II (1998-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
shift lock relay wiring diagram (1 of 2)
2 3 (W/M/T) (W/A/T OR W/M/T, CRUISE CONTROL)
4 DOOR
AMBIENT LIGHT SENSOR
BLK WIRE
CENTER HIGH MOUNTED STOPLAMP (CHMSL)
CRUISE CONTROL SERVO
DEF FUSE
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZ FUSE
HAZARD SWITCH
HEAD OFF
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR START
INSTRUMENT CLUSTER
JUNCTION BLOCK (IN LEFT KICK PANEL)
LEFT FRONT SIDE MARKER LAMP LEFT FRONT TURN SIGNAL LAMP
LEFT TAILLAMP
LEFT TURN INDICATOR
LICENSE PLATE LAMP
LIGHT SWITCH
PARK
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT TAILLAMP
RIGHT TURN INDICATOR
RUN WIRE
SHIFT LOCK RELAY
STOP FUSE
STOP TAIL
STOP TURN
STOPLAMP SWITCH
TAIL FUSE
TAIL RELAY
TAIL TURN
TRAILER HARNESS
TURN FUSE
TURN SIGNAL SWITCH
TURN SIGNAL/ HEADLAMP SWITCH
TURN/ HAZARD FLASHER
W/ A/T
W/ ABS
W/ CRUISE CONTROL
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit -> SHIFT LOCK RELAY
shift lock relay wiring diagram (2 of 2)
1.6L, 2.0L
2.0L ONLY
2.5L ONLY
28 9 17 26 6 25 (1.6L/2.0L) (2.5L)
A/C COMPRESSOR CONTROL MODULE
A/C CONDENSER FAN
A/C REFRIGERANT PRESSURE SWITCH
BATTERY
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
CRUISE CONTROL SERVO
FRONT DRIVE AXLE ACTUATOR PUMP
FRONT WASHER PUMP
FRONT WIPER MOTOR
FUEL SENDER ASSEMBLY
GRN WIRE
HEATED OXYGEN SENSOR 2 SHIELD
HORN
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INSTRUMENT CLUSTER
KNOCK SENSOR (KS) SHIELD
LAMP
LEFT FRONT SIDE MARKER
LEFT FRONT TURN SIGNAL
NCA WIRE
ORG/ WIRE
OXYGEN HEATER RELAY
POWERTRAIN CONTROL MODULE (PCM)
REAR WASHER PUMP
RIGHT FRONT SIDE MARKER
RIGHT FRONT TURN SIGNAL
SHIFT LOCK RELAY
VEHICLE SPEED SENSOR
W/ A/T
W/ CRUISE CONTROL
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> SHIFT LOCK RELAY
