Chevrolet Tracker II (1998-2004) seat belt switch right taillamp Wiring diagram
This page shows the only wiring diagram for the component.seat belt switch right taillamp, which is found in the car Chevrolet Tracker II (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat belt switch right taillamp (1 of 1)
2 DOOR ONLY
BLK WIRE
BLOWER SWITCH
CENTER HIGH MOUNTED STOPLAMP (CHMSL)
DOME LAMP
DOOR LOCK RELAY
DOOR UNLOCK RELAY
FUEL SENDER ASSEMBLY
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
LEFT TAILLAMP
LICENSE PLATE LAMP
OVERDRIVE SWITCH
REAR DEFOGGER
REMOTE CONTROL DOOR LOCK RECEIVER
SEAT BELT SWITCH RIGHT TAILLAMP
SHIFT LOCK DIODE
SHIFT LOCK SOLENOID
SHIFT PROGRAM SWITCH
SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) DATA LINK CONNECTOR (DLC) (NOT USED)
TRAILER HARNESS
W/ A/T
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> SEAT BELT SWITCH RIGHT TAILLAMP
