Chevrolet Tracker II (1998-2004) right front window regulator Wiring diagram
This page shows the only wiring diagram for the component.right front window regulator, which is found in the car Chevrolet Tracker II (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front window regulator (1 of 1)
BLK WIRE
BLU/WHT WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT IN ON
JUNCTION BLOCK (IN LEFT KICK PANEL)
LEFT FRONT WINDOW REGULATOR
LEFT FRONT WINDOW SWITCH UP
LEFT REAR WINDOW REGULATOR
LEFT REAR WINDOW SWITCH
LEFT REAR WINDOW SWITCH UP
LOCK
MASTER SWITCH
P/W FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT WINDOW REGULATOR
RIGHT FRONT WINDOW SWITCH
RIGHT FRONT WINDOW SWITCH UP
RIGHT REAR WINDOW REGULATOR
RIGHT REAR WINDOW SWITCH
RIGHT REAR WINDOW SWITCH UP
SOLID STATE AUTO DOWN CONTROL
SOLID STATE ECB
UNLOCK
WINDOW LOCK SWITCH
YEL WIRE
Go to component -> Power window circuit -> RIGHT FRONT WINDOW REGULATOR
