Chevrolet Tracker II (1998-2004) power mirror select switch Wiring diagram
This page shows the only wiring diagram for the component.power mirror select switch, which is found in the car Chevrolet Tracker II (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power mirror select switch (1 of 1)
BLK WIRE
BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
CIG FUSE
DOWN
DOWN UP
DOWN UP LEFT RIGHT
DOWN UP UP
GRN/WHT WIRE
GRY WIRE
HOT IN ACC, RUN
JUNCTION BLOCK (IN LEFT KICK PANEL)
LEFT OUTSIDE MIRROR
LEFT RIGHT
LEFT/ RIGHT MOTOR
LT GRN/BLK WIRE
POWER MIRROR SELECT SWITCH
PPL PPL
REMOTE CONTROL MIRROR SWITCH
RIGHT LEFT
RIGHT OUTSIDE MIRROR
UP/ DOWN MOTOR
WHT/BLK WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> POWER MIRROR SELECT SWITCH
