Chevrolet Tracker II (1998-2004) map lamps switch Wiring diagram
This page shows the only wiring diagram for the component.map lamps switch, which is found in the car Chevrolet Tracker II (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram map lamps switch (1 of 1)
3 BULBS
4 DOOR
AMBIENT LIGHT SENSOR
ASHTRAY LAMP
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
CIGAR LIGHTER LAMP HAZARD SWITCH
DOME FUSE
DOME LAMP
DOME LAMP DIODE
DOOR
GRN WIRE
GRY WIRE
HEAD OFF
HEATER CONTROL ILLUMINATION LAMP
HOT AT ALL TIMES
I/P LAMPS DIMMERS CONTROL
INSTRUMENT CLUSTER
JUNCTION BLOCK (IN LEFT KICK PANEL)
LEFT DOOR JAMB SWITCH (2-DOOR)
LEFT FRONT DOOR JAMB SWITCH (4-DOOR)
LEFT REAR DOOR JAMB SWITCH (4 DOOR)
LIGHT SWITCH
MAIN CRUISE CONTROL SWITCH
MAP LAMPS SWITCH
OFF
OFF ON
POWER SOLID STATE GROUND BULBS
RADIO
REAR DEFOGGER SWITCH
REAR DOME LAMP (4-DOOR)
REAR DOOR JAMB SWITCH
REAR WIPER/ WASHER SWITCH
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT DOOR JAMB SWITCH (2-DOOR)
RIGHT FRONT DOOR JAMB SWITCH (4-DOOR)
RIGHT REAR DOOR JAMB SWITCH (4-DOOR)
SHIFT INDICATOR LAMP (W/ A/T)
SHIFT PROGRAM SWITCH (W/ 4-SPEED A/T ONLY)
TAIL
TAIL FUSE
TAIL LAMP RELAY
WARNING SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Interior light circuit -> MAP LAMPS SWITCH
