Chevrolet Tracker II (1998-2004) lights on Wiring diagram
This page shows the only wiring diagram for the component.lights on, which is found in the car Chevrolet Tracker II (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lights on (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
DOME FUSE
DR OPEN
EXTERIOR/ INTERIOR LIGHTS SYSTEM
GRN WIRE
GROUND MULTIFUNCTION ALARM
GRY WIRE
GRY/RED WIRE
HEAD OFF PARK
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON, START
IG FUSE
IGN KEY SIG ST BLT IND
IGNITION
IGNITION KEY-IN SWITCH
INFLATABLE RESTRAINT SYSTEM
INSTRUMENT CLUSTER
JUNCTION BLOCK
LEFT FRONT DOOR JAMB SWITCH
LIGHTS ON
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
SEAT BELT IND
SEAT BELT SWITCH
TAIL FUSE
TAIL RELAY
TURN SIGNAL/ HEADLAMP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits -> LIGHTS ON
