Car Wiring Diagrams for Electronic power steering circuit for Chevrolet Tahoe V (2021-2024)

AUTOSAR CAN BUS (+) 1 SERIAL DATA AUTOSAR CAN BUS (+) 5 SERIAL DATA BATTERY DISTRIBUTION ENGINE COMPARTMENT FUSE BLOCK BATTERY POSITIVE VOLT BLK WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY GRN WIRE GRY WIRE HAND WHEEL CHANNEL A ANGLE POSI SENS SENT SIG HAND WHEEL CHANNEL A LO REF HAND WHEEL CHANNEL A TORQUE PRESS SENS 1 SENT SIG HAND WHEEL CHANNEL A HI REF HAND WHEEL CHANNEL A TORQUE PRESS SENS 2 SENT SIG HAND WHEEL CHANNEL B ANGLE POSI SENS SENT SIG HAND WHEEL CHANNEL B HI REF HAND WHEEL CHANNEL B LO REF HAND WHEEL CHANNEL B TORQUE PRESS SENS 1 SENT SIG HAND WHEEL CHANNEL B TORQUE PRESS SENS 2 SENT SIG HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE LOGIC ORG/ WIRE POS A POS B POWER STEERING ASSIST MOTOR POWER STEERING CONTROL MODULE (POWER STEERING RACK ASSEMBLY) POWER STEERING SHAFT TORQUE/ POSITION SENSOR RED WIRE VIO WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE
