Chevrolet Tahoe V (2021-2024) rear climate switch Wiring diagram
This page shows the only wiring diagram for the component.rear climate switch, which is found in the car Chevrolet Tahoe V (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear climate switch (1 of 1)
A/C IND
A/C SWITCH
AIR CONDITIONING CLUTCH
AIR CONDITIONING COMPRESSOR
AIR CONDITIONING COMPRESSOR SOLENOID VALVE
AIR CONDITIONING EVAPORATOR AIR TEMPERATURE SENSOR
AUTO IND
AUTO SWITCH
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
CHARGE AIR COOLER COOLANT PUMP
COMPUTER DATA LINES SYSTEM
DEFROST, LOWER AIR OUTLET IND
DEFROST, LOWER AIR OUTLET SWITCH
DISPLAY
FRONT HEATER, AIR CONDITIONING USER INTERFACE CONTROL
GRN/VIO WIRE
GRY WIRE
GRY/GRN WIRE
HEADLIGHTS SYSTEM
LOGIC
LOWER AIR OUTLET IND
LOWER AIR OUTLET SWITCH
MAX WINDSHIELD DEFROST IND
MAX WINDSHIELD DEFROST SWITCH
NCA WIRE
ON/OFF SWITCH
REAR CLIMATE SWITCH
REAR ON/OFF IND
REAR ON/OFF SWITCH
RECIRCULATION IND
RECIRCULATION SWITCH
RED/WHT WIRE
RED/YEL WIRE
SUNLOAD, AMBIENT LIGHT, SECURITY INDICATOR SENSOR
SYNC IND
SYNC SWITCH
UPPER AIR OUTLET SWITCH
VIO/BLU WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/YEL WIRE
Go to component -> Automatic a/c circuit (3 of 7) -> REAR CLIMATE SWITCH
