Chevrolet Tahoe V (2021-2024) instrument panel light conductor inner lamp Wiring diagram
This page shows the only wiring diagram for the component.instrument panel light conductor inner lamp, which is found in the car Chevrolet Tahoe V (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument panel light conductor inner lamp (1 of 1)
BLK WIRE
BLU/GRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
GRN/WHT WIRE
GRY/GRN WIRE
INSTRUMENT PANEL LIGHT CONDUCTOR INNER LAMP
LOGIC
PASSENGER HANDLE FRONT SIDE DOOR LIGHT CONDUCTOR LAMP
PASSENGER TRIM PANEL FRONT SIDE DOOR LIGHT CONDUCTOR LAMP
RIGHT FRONT SIDE DOOR INSIDE HANDLE ILLUMINATION LAMP
RIGHT FRONT SIDE DOOR MAP POCKET ILLUMINATION LAMP
RIGHT REAR FLOOR COURTESY LAMP
RIGHT REAR SIDE DOOR INSIDE HANDLE ILLUMINATION LAMP
RIGHT REAR SIDE DOOR POCKET ILLUMINATION LAMP
WHT/VIO WIRE
Go to component -> Courtesy lamps circuit (7 of 9) -> INSTRUMENT PANEL LIGHT CONDUCTOR INNER LAMP
