Chevrolet Tahoe V (2021-2024) high beam select switch high beam signal Wiring diagram
This page shows the only wiring diagram for the component.high beam select switch high beam signal, which is found in the car Chevrolet Tahoe V (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high beam select switch high beam signal (1 of 1)
AMBIENT LIGHT SENSOR SIGNAL
AUTO
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BODY CONTROL MODULE LIN BUS 6
COMPUTER DATA LINES SYSTEM
DIMMER SWITCH
DRIVER INFORMATION CENTER DISPLAY
DRL IND
ENGINE WIRING HARNESS JUNCTION BLOCK
FOG LAMP IND
FRONT FOG LAMP SWITCH
GRN/BLK WIRE
GRN/BRN WIRE
GRN/VIO WIRE
HEAD
HEADLAMP SWITCH
HEADLAMP SWITCH FLASH SIGNAL
HEADLAMP SWITCH OFF SIGNAL
HEADLAMP SWITCH ON SIGNAL
HEADLAMP SWITCH REFERENCE
HEADLAMP SWITCH SIGNAL
HIGH BEAM LAMP IND
HIGH BEAM SELECT SWITCH HIGH BEAM SIGNAL
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LIN BUS 1
LOGIC
OFF
PARK
REAR FOG LAMP SWITCH
RED/BRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
SENSOR LOW REFERENCE
TURN SIGNAL SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Headlights circuit (1 of 3) -> HIGH BEAM SELECT SWITCH HIGH BEAM SIGNAL
