Car Wiring Diagrams for Retractable running boards circuit for Chevrolet Tahoe IV (2014-2021)

ASSIST STEP CONTROL MODULE BATT POS VOLT BLK WIRE BLU WIRE BLU/YEL WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH) BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DISABLE SW SIG DK GRN WIRE ECO SW SIG ELEC RNG BDS FUSE GMC/CHEVROLET GMLAN SERIAL DATA GRN WIRE GRN/RED WIRE GROUND GRY WIRE GRY/GRN WIRE HILL DESCENT CTRL SW SIG HOT AT ALL TIMES INSTRUMENT PANEL MULTI- FUNCTION SWITCH INSTRUMENT PANEL MULTI-FUNCTION SWITCH 1 LEFT ASSIST STEP (UNDER DRIVER'S DOOR) LEFT RUNNING BOARD STEP COURTESY LAMP LH CTRL EXTEND LH CTRL RETRACT LOGIC MTR HALL SENS LH REF MTR HALL SENS RH REF RED/YEL WIRE RH CTRL EXTEND RH CTRL RETRACT RIGHT ASSIST STEP (UNDER PASSENGER'S DOOR) RIGHT RUNNING BOARD STEP COURTESY LAMP SENS LH RTN SENS LH SIG SENS RH RTN SENS RH SIG SERIAL DATA (-) (1) UNDERHOOD FUSE BLOCK VIO WIRE VIO/RED WIRE WHT WIRE WHT/BRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
