Chevrolet Tahoe IV (2014-2021) sens rh rtn wiring diagram
This page shows the only wiring diagram for the component.sens rh rtn, which is found in the car Chevrolet Tahoe IV (2014-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sens rh rtn wiring diagram (1 of 1)
ASSIST STEP CONTROL MODULE
BATT POS VOLT
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DISABLE SW SIG
DK GRN WIRE
ECO SW SIG
ELEC RNG BDS FUSE
GMC/CHEVROLET
GMLAN SERIAL DATA
GRN WIRE
GRN/RED WIRE
GROUND
GRY WIRE
GRY/GRN WIRE
HILL DESCENT CTRL SW SIG
HOT AT ALL TIMES
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 1
LEFT ASSIST STEP (UNDER DRIVER'S DOOR)
LEFT RUNNING BOARD STEP COURTESY LAMP
LH CTRL EXTEND
LH CTRL RETRACT
LOGIC
MTR HALL SENS LH REF
MTR HALL SENS RH REF
RED/YEL WIRE
RH CTRL EXTEND
RH CTRL RETRACT
RIGHT ASSIST STEP (UNDER PASSENGER'S DOOR)
RIGHT RUNNING BOARD STEP COURTESY LAMP
SENS LH RTN
SENS LH SIG
SENS RH RTN
SENS RH SIG
SERIAL DATA (-) (1)
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/RED WIRE
WHT WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Retractable running boards circuit -> SENS RH RTN
