Chevrolet Tahoe IV (2014-2021) left rear exterior door handle courtesy lamp Wiring diagrams

B+ VOLT BLK WIRE BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONTENT THEFT DETERRENT SENSOR DISABLE SWITCH CONTENT THEFT DETERRENT SENSOR MODULE DATA BUS 1 GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRY/GRN WIRE HOT AT ALL TIMES LEFT INSTRUMENT PANEL FUSE BLOCK LEFT REAR EXTERIOR DOOR HANDLE ASSEMBLY LEFT REAR EXTERIOR DOOR HANDLE COURTESY LAMP LEFT REAR EXTERIOR DOOR HANDLE SWITCH LIN SERIAL DATA LOGIC NETWORK BUS 2 OVERHEAD CONSOLE POWER SOUNDER CONTENT THEFT DETERRENT ALARM MODULE RED WIRE RED/BLU WIRE RED/GRY WIRE RIGHT REAR EXTERIOR DOOR HANDLE ASSEMBLY RIGHT REAR EXTERIOR DOOR HANDLE COURTESY LAMP RIGHT REAR EXTERIOR DOOR HANDLE SWITCH SW DISABLE SIG SW LED CTRL THEFT DTRNT FUSE ULTRASONIC INTRUSION SENSOR 1 ULTRASONIC INTRUSION SENSOR 2 ULTRASONIC INTRUSION SENSOR 3 VIO/BLK WIRE VIO/YEL WIRE WHT WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/GRY WIRE

BLK WIRE BLU WIRE DRIVER BACK SEAT BLOWER ASSEMBLY DRIVER BACK SEAT HEATING ELEMENT DRIVER CUSHION SEAT BLOWER ASSEMBLY DRIVER CUSHION SEAT HEATING ELEMENT DRIVER DOOR ACCENT LAMP DRIVER DOOR HANDLE ACCENT LAMP DRIVER DOOR HANDLE FLOOD LAMP DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR LOCK SWITCH DRIVER DOOR SILL PLATE LAMP DRIVER EXTERIOR DOOR HANDLE ASSEMBLY DRIVER EXTERIOR DOOR HANDLE COURTESY LAMP DRIVER EXTERIOR DOOR HANDLE SWITCH DRIVER LEFT REAR SEAT HAPTIC MOVEMENT MOTOR DRIVER OUTSIDE REAR VIEW MIRROR COURTESY LAMP DRIVER OUTSIDE REAR VIEW MIRROR GLASS DRIVER RIGHT REAR SEAT HAPTIC MOVEMENT MOTOR DRIVER SEAT ACCENT LAMP DRIVER SEAT BOLSTER MEMORY CONTROL MODULE DRIVER SEAT LUMBAR/ BOLSTER PUMP DRIVER SEAT MEMORY CONTROL MODULE DRIVER SEAT SWITCH ADJUSTER DRIVER SIDE OBJECT DETECTION INDICATOR DRIVER WINDOW MOTOR DRIVER WINDOW SWITCH GMC/ CHEVROLET LEFT REAR COMPARTMENT POWER RECEPTACLE LEFT REAR CUSHION HEATED SEAT ELEMENT LEFT REAR DOOR ACCENT LAMP LEFT REAR DOOR HANDLE ACCENT LAMP LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR DOOR POCKET FLOOD LAMP LEFT REAR DOOR SILL PLATE LAMP LEFT REAR EXTERIOR DOOR HANDLE ASSEMBLY LEFT REAR EXTERIOR DOOR HANDLE COURTESY LAMP LEFT REAR EXTERIOR DOOR HANDLE SWITCH LEFT REAR WINDOW SWITCH LEFT SEAT BELT RETRACTOR MOTOR MODULE LEFT TURN SIGNAL REPEATER LAMP LIFTGATE WINDOW UNLATCH RELAY NCA WIRE OUTSIDE REAR VIEW MIRROR HEATER RELAY OUTSIDE REAR VIEW MIRROR SWITCH POWER SOUNDER CONTENT THEFT DETERRENT ALARM MODULE REAR BODY FUSE BLOCK REAR DEFOGGER RELAY REAR SEAT HEATING CONTROL MODULE RED WIRE W/ FRONT SEAT HEATER, COOLING W/ HEATED MIRROR W/ MEMORY W/O MEMORY W/ POWER FOLD WHT WIRE

B+ VOLT BLK WIRE BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONTENT THEFT DETERRENT SENSOR DISABLE SWITCH CONTENT THEFT DETERRENT SENSOR MODULE DATA BUS 1 GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRY/GRN WIRE HOT AT ALL TIMES LEFT INSTRUMENT PANEL FUSE BLOCK LEFT REAR EXTERIOR DOOR HANDLE ASSEMBLY LEFT REAR EXTERIOR DOOR HANDLE COURTESY LAMP LEFT REAR EXTERIOR DOOR HANDLE SWITCH LIN SERIAL DATA LOGIC NETWORK BUS 2 OVERHEAD CONSOLE POWER SOUNDER CONTENT THEFT DETERRENT ALARM MODULE RED WIRE RED/BLU WIRE RED/GRY WIRE RIGHT REAR EXTERIOR DOOR HANDLE ASSEMBLY RIGHT REAR EXTERIOR DOOR HANDLE COURTESY LAMP RIGHT REAR EXTERIOR DOOR HANDLE SWITCH SW DISABLE SIG SW LED CTRL THEFT DTRNT FUSE ULTRASONIC INTRUSION SENSOR 1 ULTRASONIC INTRUSION SENSOR 2 ULTRASONIC INTRUSION SENSOR 3 VIO/BLK WIRE VIO/YEL WIRE WHT WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/GRY WIRE
