Chevrolet Tahoe IV (2014-2021) left rear door sill plate lamp Wiring diagrams

BLK WIRE BRN WIRE CENTER CONSOLE FLOOD LAMP COMPUTER DATA LINES SYSTEM DOME LAMP DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR SILL PLATE LAMP GRN/GRY WIRE GRN/YEL WIRE GRY WIRE GRY/WHT WIRE INSTRUMENT ILLUMINATION CIRCUIT INSTRUMENT PANEL JUNCTION BLOCK LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR DOOR SILL PLATE LAMP LEFT REAR WINDOW SWITCH LF DOOR AJAR SW SIG LOGIC LOGIC DRIVER WINDOW MOTOR LOGIC PASSENGER WINDOW MOTOR LOGIC RIGHT REAR WINDOW SWITCH LR DOOR AJAR SW SIG NETWORK 3 NETWORK BUS 4 PASSENGER DOOR LATCH ASSEMBLY PASSENGER DOOR SILL PLATE LAMP RF DOOR AJAR SW SIG RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR DOOR SILL PLATE LAMP RR DOOR AJAR SW SIG VIO/GRN WIRE W/ ADDITIONAL VIDEO SCREEN EQUIPMENT W/O ADDITIONAL VIDEO SCREEN EQUIPMENT WHT WIRE WHT/BRN WIRE YEL WIRE

BLK WIRE BLU WIRE DRIVER BACK SEAT BLOWER ASSEMBLY DRIVER BACK SEAT HEATING ELEMENT DRIVER CUSHION SEAT BLOWER ASSEMBLY DRIVER CUSHION SEAT HEATING ELEMENT DRIVER DOOR ACCENT LAMP DRIVER DOOR HANDLE ACCENT LAMP DRIVER DOOR HANDLE FLOOD LAMP DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR LOCK SWITCH DRIVER DOOR SILL PLATE LAMP DRIVER EXTERIOR DOOR HANDLE ASSEMBLY DRIVER EXTERIOR DOOR HANDLE COURTESY LAMP DRIVER EXTERIOR DOOR HANDLE SWITCH DRIVER LEFT REAR SEAT HAPTIC MOVEMENT MOTOR DRIVER OUTSIDE REAR VIEW MIRROR COURTESY LAMP DRIVER OUTSIDE REAR VIEW MIRROR GLASS DRIVER RIGHT REAR SEAT HAPTIC MOVEMENT MOTOR DRIVER SEAT ACCENT LAMP DRIVER SEAT BOLSTER MEMORY CONTROL MODULE DRIVER SEAT LUMBAR/ BOLSTER PUMP DRIVER SEAT MEMORY CONTROL MODULE DRIVER SEAT SWITCH ADJUSTER DRIVER SIDE OBJECT DETECTION INDICATOR DRIVER WINDOW MOTOR DRIVER WINDOW SWITCH GMC/ CHEVROLET LEFT REAR COMPARTMENT POWER RECEPTACLE LEFT REAR CUSHION HEATED SEAT ELEMENT LEFT REAR DOOR ACCENT LAMP LEFT REAR DOOR HANDLE ACCENT LAMP LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR DOOR POCKET FLOOD LAMP LEFT REAR DOOR SILL PLATE LAMP LEFT REAR EXTERIOR DOOR HANDLE ASSEMBLY LEFT REAR EXTERIOR DOOR HANDLE COURTESY LAMP LEFT REAR EXTERIOR DOOR HANDLE SWITCH LEFT REAR WINDOW SWITCH LEFT SEAT BELT RETRACTOR MOTOR MODULE LEFT TURN SIGNAL REPEATER LAMP LIFTGATE WINDOW UNLATCH RELAY NCA WIRE OUTSIDE REAR VIEW MIRROR HEATER RELAY OUTSIDE REAR VIEW MIRROR SWITCH POWER SOUNDER CONTENT THEFT DETERRENT ALARM MODULE REAR BODY FUSE BLOCK REAR DEFOGGER RELAY REAR SEAT HEATING CONTROL MODULE RED WIRE W/ FRONT SEAT HEATER, COOLING W/ HEATED MIRROR W/ MEMORY W/O MEMORY W/ POWER FOLD WHT WIRE
