Chevrolet Tahoe IV (2014-2021) driver seat lumbar support horizontal motor Wiring diagram
This page shows the only wiring diagram for the component.driver seat lumbar support horizontal motor, which is found in the car Chevrolet Tahoe IV (2014-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat lumbar support horizontal motor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DOWN
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT LUMBAR SUPPORT HORIZONTAL MOTOR
DRIVER SEAT REAR VERTICAL MOTOR
DRIVER SEAT RECLINE MOTOR
DRVR PWR SEAT FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT INSTRUMENT PANEL FUSE BLOCK
RECLINE FWD
RECLINE RWD
RED WIRE
RWD
VIO WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> DRIVER SEAT LUMBAR SUPPORT HORIZONTAL MOTOR
