Chevrolet Tahoe IV (2014-2021) cam shaft lo ref Wiring diagram
This page shows the only wiring diagram for the component.cam shaft lo ref, which is found in the car Chevrolet Tahoe IV (2014-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cam shaft lo ref (1 of 1)
BLK/BRN WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CAM SHAFT LO REF
CAMSHAFT POSITION ACTUATOR SOLENOID VALVE
CAMSHAFT POSITION SENSOR
CRANKSHAFT POSITION SENSOR
ENGINE CONTROL MODULE
EVAPORATIVE EMISSION PURGE SOLENOID VALVE
FUEL INJECTOR 2
FUEL INJECTOR 7
FUEL INJECTOR 8
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/WHT WIRE
LOW REF
SENS SIG
SENS VOLT
SIG
SIG GND
SOLENOID CTRL 1
SOLENOID CTRL 2
SPLY CYLINDER 1
SPLY CYLINDER 2
SPLY CYLINDER 3
SPLY CYLINDER 4
SPLY CYLINDER 5
SPLY CYLINDER 6
SPLY CYLINDER 7
SPLY CYLINDER 8
VIO WIRE
VIO/BLU WIRE
VIO/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/GRY WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 5.3l vin c (6 of 8) -> CAM SHAFT LO REF
