Driver power seat circuit for Chevrolet Tahoe III (2006-2014)
Driver power seat circuit
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DOWN
DRIVER SEAT 2 CIRCUIT BREAKER
DRIVER SEAT ADJUSTER ASSEMBLY (UNDER DRIVER'S SEAT)
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT REAR VERTICAL MOTOR
HOT AT ALL TIMES
LEFT I/P JUNCTION BLOCK (LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
NCA WIRE
RED/WHT WIRE
RWD
TAN WIRE
YEL WIRE
