Adjustable pedal circuit for Chevrolet Tahoe III (2006-2014)
Adjustable pedal circuit
BLK WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
EAP FUSE 38
EAP PCB RELAY
ELECTRONIC ADJUSTABLE PEDAL (EAP) ASSEMBLY (BRAKE PEDAL ASSEMBLY)
HOT AT ALL TIMES
I/P MULTI-FUNCTION SWITCH
LEFT I/P JUNCTION BLOCK (LEFT END OF DASH)
ORG/BLK WIRE
PARK ENABLE PCB RELAY
PPL
RED/WHT WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
YEL/BLK WIRE
