Chevrolet Tahoe III (2006-2014) power distribution system 5060 2500 2501 Wiring diagram
This page shows the only wiring diagram for the component.power distribution system 5060 2500 2501, which is found in the car Chevrolet Tahoe III (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power distribution system 5060 2500 2501 (1 of 1)
10 16 17 LOW SPD GMLAN DATA BUS+ DATA BUS-
10 9 8 LOW REF SNS SIG SNS CTRL
23 25 32 61 GEN SIG CHG IND
2500 2501 28 27 DATA BUS+ DATA BUS-
BATTERY
BATTERY CURRENT SENSOR (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CHARGE IND
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
FUSE HOLDER (ON POSITIVE BATTERY POST) COMPUTER DATA LINES SYSTEM
GENERATOR
GMC, CHEVROLET CADILLAC
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
IPC FUSE 46
LOGIC
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM 5060 2500 2501
POWER DISTRIBUTION SYSTEM 5077 5075 5076
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
STARTING CIRCUIT
TAN WIRE
TAN/BLK WIRE
VOLT
WHT WIRE
Go to component -> Charging circuit -> POWER DISTRIBUTION SYSTEM 5060 2500 2501
