Chevrolet Tahoe III (2006-2014) passenger heated seat back switch signal Wiring diagram

1 2 3 4 5 6 7 8 BATT POS VOLT GROUND BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE FUSE 37 GRY WIRE HEATED SEAT CONTROL MODULE HOT AT ALL TIMES LEFT I/P JUNCTION BLOCK (LEFT END OF DASH) LT BLU WIRE LT GRN WIRE NCA WIRE PASSENGER BACK HEATED SEAT ELEMENT (FRONT PASSENGER'S SEAT BACK) PASSENGER CUSHION HEATED SEAT ELEMENT (FRONT PASSENGER'S SEAT CUSHION) PASSENGER HEATED SEAT BACK SWITCH SIGNAL PNK LOW REF LOW REF LOW REF LOW REF WIRE PNK WIRE PPL PPL 18 19 RED WIRE RED/WHT WIRE TAN WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
