Chevrolet Tahoe III (2006-2014) i/p multi-function switch chevrolet, gmc cadillac Wiring diagram
This page shows the only wiring diagram for the component.i/p multi-function switch chevrolet, gmc cadillac, which is found in the car Chevrolet Tahoe III (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram i/p multi-function switch chevrolet, gmc cadillac (1 of 1)
10 VOLT REF 10 VOLT REF SENS LEFT SIG SENS RIGHT SIG LOW REFERENCE LOW REFERENCE
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
ELEC RUN BOARD FUSE 65
GMLAN SERIAL GMLAN SERIAL DISABLE SIGNAL
GRY WIRE
HOT AT ALL TIMES
I/P MULTI-FUNCTION SWITCH CHEVROLET, GMC CADILLAC
LEFT RUNNING BOARD (UNDER LEFT SIDE OF VEHICLE)
LOGIC ASSIST STEP CONTROL MODULE (UNDER LEFT CENTER OF VEHICLE)
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
R CTRL RETRACT GROUND L CTRL EXTEND R CTRL EXTEND BATT L CTRL RETRACT
RED/BLK WIRE
RIGHT RUNNING BOARD (UNDER RIGHT SIDE OF VEHICLE)
TAN WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/O SIDE OBSTACLE DETECTION SENSOR W/ OBSTACLE DETECTION SENSOR
YEL WIRE
YEL/BLK WIRE
Go to component -> Retractable running boards circuit -> I/P MULTI-FUNCTION SWITCH CHEVROLET, GMC CADILLAC
