Chevrolet Tahoe III (2006-2014) air outlet drive motor battery temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.air outlet drive motor battery temperature sensor, which is found in the car Chevrolet Tahoe III (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air outlet drive motor battery temperature sensor (1 of 1)
1 2 3 4 NOT USED MTR PWR FEED GROUND 5-VOLT REF
8 36 56 51 72 PUMP RLY CTRL LOW REF 5-VOLT REF GMLAN SER DATA - GMLAN SER DATA +
AIR INLET DRIVE MOTOR BATTERY TEMPERATURE SENSOR
AIR OUTLET DRIVE MOTOR BATTERY TEMPERATURE SENSOR
AUXILIARY FUSE
BECM FAN FUSE 2
BLK WIRE
BLK/YEL WIRE
BLOCK (LEFT SIDE OF ENGINE COMPT)
BLU WIRE
COMPUTER DATA LINES SYSTEM
COOL PUMP FUSE 6
COOL PUMP RELAY
DK BLU WIRE
DK GRN WIRE
DK GRN/BLK WIRE
DRIVE MOTOR BATTERY TEMPERATURE SENSOR 1
DRIVE MOTOR BATTERY TEMPERATURE SENSOR 2
DRIVE MOTOR BATTERY TEMPERATURE SENSOR 3
DRIVE MOTOR BATTERY TEMPERATURE SENSOR 4
DRIVE MOTOR GENERATOR BATTERY
DRIVE MOTOR GENERATOR BATTERY CONTROL MODULE
ENGINE COMPT)
ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT)
FROM DRIVE MOTOR BATTERY CURRENT SENSOR (DIAGRAM 4 OF 5)
FROM DRIVE MOTOR GENERATOR BATTERY CONTROL MODULE (DIAGRAM 4 OF 5)
GENERATOR BATTERY VENT FAN
GENERATOR BATTERY VENT FAN RELAY
GENERATOR CONTROL MODULE TEMPERATURE SENSOR (RIGHT FRONT OF
GRN WIRE
HOT AT ALL TIMES
LEFT GENERATOR CONTROL MODULE COOLANT PUMP (LEFT FRONT OF ENGINE COMPT)
ORG/ WIRE
PNK/DK BLU WIRE
RED WIRE
RED/WHT WIRE
RIGHT GENERATOR CONTROL MODULE COOLANT PUMP (CENTER FRONT OF ENGINE COMPT)
SENS REF
SENS RTN
SENS SIG
TAN WIRE
TAN/BLK WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 6.0l vin j, hybrid system circuit (5 of 5) -> AIR OUTLET DRIVE MOTOR BATTERY TEMPERATURE SENSOR
