Chevrolet Tahoe III (2006-2014) 1 2 3 5704 6188 5706 endgate rly coil l/glass ctrl endgate rly coil Wiring diagram

1 2 3 5704 6188 5706 ENDGATE RLY COIL L/GLASS CTRL ENDGATE RLY COIL 13 12 24 REAR SW OPEN SIG LIFTGATE AJAR SW L/GLASS SIG BLK PNK/ WIRE BLK WIRE BLU LT WIRE BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH) CHEVROLET/ GMC CADILLAC COMPUTER DATA LINES SYSTEM CONNECTOR ADAPTER DK GRN WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY GMLAN SERIAL GRY WIRE HOT AT ALL TIMES GENERATOR INLINE FUSE HOT AT ALL TIMES I/P FUSE BLOCK RT STOP (LEFT END TURN OF DASH) FUSE L/GATE PCB RELAY L/GATE RELSE FUSE 44 LIFTGATE HANDLE SWITCH LIFTGATE LATCH ASSEMBLY (CENTER OF LIFTGATE) LIFTGATE WINDOW LATCH ASSEMBLY LIFTGATE WINDOW LIFTGATE WINDOW AJAR SWITCH RELEASE ACTUATOR LIFTGATE WINDOW RELEASE SWITCH LOGIC LOGIC INSTRUMENT PANEL CLUSTER (IPC) LT BLU WIRE NCA WIRE PNK PNK WIRE PNK/BLK WIRE REAR WINDOW WIPER MOTOR (CENTER OF LIFTGATE) RED/BLK WIRE RED/WHT WIRE TAN WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WIPER/ WASHER SYSTEM YEL WIRE
