Front wiper/washer circuit for Chevrolet Tahoe II (1999-2006)

Front wiper/washer circuit

Get access

ACCESSORY VOLTAGE BLK WIRE DK BLU WIRE GROUND LSD GRY WIRE HI LO OFF HOT AT ALL TIMES HOT IN RUN AND ACC LEFT I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LO PULSE MIST MIST WASH OFF ORG/ WIRE PNK WIRE RED WIRE TAN WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT) W/S WASH FUSE W/S WASH RELAY W/S WIPER FUSE WHT WIRE WINDSHIELD WASHER FLUID PUMP (ON WASHER FLUID RESERVOIR) WINDSHIELD WASHER RELAY CNTRL WINDSHIELD WIPER HIGH SIGNAL WINDSHIELD WIPER MOTOR MODULE (LEFT SIDE OF COWL) WINDSHIELD WIPER SUPPLY VOLTAGE WINDSHIELD WIPER SWITCH SIGNAL WINDSHIELD WIPER/ WASHER SWITCH YEL WIRE
