Chevrolet Tahoe II (1999-2006) right lift- gate ajar switch Wiring diagram
This page shows the only wiring diagram for the component.right lift- gate ajar switch, which is found in the car Chevrolet Tahoe II (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right lift- gate ajar switch (1 of 1)
AJAR BATTERY PULSE WASH
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW LEFT SIDE OF DASH)
DK GRN WIRE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN AND ACC
LEFT I/P FUSE BLOCK (BELOW LEFT SIDE OF DASH)
LIFT- GLASS AJAR SWITCH LEFT LIFT- GATE AJAR SWITCH
LIFTGATE AJAR SWITCH SIGNAL
MULTIFUNCTION ACCESSORY SWITCH
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
PULSE 1
PULSE 2 WASH
REAR WINDOW WASHER FLUID PUMP (IN WASHER FLUID RESERVOIR)
REAR WINDOW WIPER MODULE (IN LIFTGATE, BELOW REAR GLASS)
REAR WIPER/ WASHER SWITCH
RIGHT LIFT- GATE AJAR SWITCH
RR WPR FUSE
UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPARTMENT, NEAR BATTERY)
WHT WIRE
YEL WIRE
Go to component -> Rear wiper/washer circuit -> RIGHT LIFT- GATE AJAR SWITCH
