Chevrolet Tahoe II (1999-2006) right cargo door ajar switch Wiring diagrams
This page contains all the electrical diagrams for the component. right cargo door ajar switch, in which he is found in the car Chevrolet Tahoe II (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right cargo door ajar switch (1 of 2)
22 3 11 SERIAL DATA LEFT SEAT BELT SW LOW REFERENCE
22 3 18 SERIAL DATA LOW REFERENCE LEFT DOOR AJAR SW
22 5 20 SERIAL DATA DOOR AJAR SWITCH LOW REFERENCE
59 58 SERIAL DATA SERIAL DATA
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DRIVER DOOR MODULE (DDM) (IN DRIVER'S DOOR)
DRIVER MINI-WEDGE DOOR JAMB SWITCH
DRIVER SEAT BELT SWITCH
FRONT PASSENGER DOOR MODULE (FPDM) (IN RIGHT FRONT DOOR)
GRY WIRE
GRY/BLK WIRE
IGN
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER LEFT FRONT SEAT)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH)
LEFT LIFTGATE AJAR SWITCH
LEFT TURN
LIFTGLASS AJAR SWITCH
LOGIC
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER MINI WEDGE (DOOR JAMB SWITCH)
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (PCM) (AT LEFT FRONT OF ENGINE COMPARTMENT)
PPL
PPL PPL 1132 1807
RADIO
RIGHT CARGO DOOR AJAR SWITCH
RIGHT DOOR CONTACT PLATE (BODY)
RIGHT DOOR CONTACT PLATE (DOOR)
RIGHT I/P FUSE BLOCK (ON LOWER RIGHT SIDE OF DASH)
RIGHT LIFTGATE AJAR SWITCH
RIGHT TURN
SEAT BELT
SERIAL DATA
SPLICE PACK
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
W/ANTI-THEFT SYSTEM 1036 1044 1045
W/CARGO DOORS
W/O CARGO DOORS
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Chime circuit (2 of 2) -> RIGHT CARGO DOOR AJAR SWITCH
Wiring diagram right cargo door ajar switch (2 of 2)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN)
BRN WIRE
CLASS 2 DATA
CLASS 2 SERIAL DATA
CTSY LAMP CTRL
CTSY LAMP ON SIG
CTSY LAMP POWER
CTSY LAMP SUPPLY
DK BLU WIRE
DK BLU/WHT WIRE
DOME LAMP SWITCH
DOOR AJAR SIG
DRIVER DOOR MODULE (BEHIND LEFT FRNT DOOR TRIM PANEL, NEAR HANDLE
GRY/BLK WIRE
HEADLAMP SWITCH
INADVERTANT PWR SUPPLY
LEFT FRONT DOOR COURTESY LAMP
LEFT LIFTGATE AJAR SWITCH RIGHT LIFTGATE AJAR SWITCH
LIFTGATE AJAR SIG RR DOOR AJAR SIG LR DOOR AJAR SIG
LIFTGLASS AJAR SWITCH
LOW REF
LR DOOR COURTESY LAMP (2003)
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MINI WEDGE (DRIVER DOOR JAMB SWITCH)
MINI WEDGE (LR DOOR JAMB SWITCH)
MINI WEDGE (RR DOOR JAMB SWITCH)
ORG/ WIRE
PNK/BLK WIRE
PPL INT LAMP DEFEAT SIG
PPL INT LAMP DEFEAT SW
RIGHT CARGO DOOR AJAR SWITCH
RIGHT CARGO DOOR CONTACT PLATE
RR DOOR COURTESY LAMP (2003)
SPLICE PACK
TAN WIRE
W/O CARGO DOORS W/ CARGO DOORS
Go to component -> Courtesy lamps circuit (1 of 3) -> RIGHT CARGO DOOR AJAR SWITCH
