Chevrolet Tahoe II (1999-2006) liftgate ajar sig rr door ajar sig lr door ajar sig Wiring diagram
This page shows the only wiring diagram for the component.liftgate ajar sig rr door ajar sig lr door ajar sig, which is found in the car Chevrolet Tahoe II (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate ajar sig rr door ajar sig lr door ajar sig (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN)
BRN WIRE
CLASS 2 DATA
CLASS 2 SERIAL DATA
CTSY LAMP CTRL
CTSY LAMP ON SIG
CTSY LAMP POWER
CTSY LAMP SUPPLY
DK BLU WIRE
DK BLU/WHT WIRE
DOME LAMP SWITCH
DOOR AJAR SIG
DRIVER DOOR MODULE (BEHIND LEFT FRNT DOOR TRIM PANEL, NEAR HANDLE
GRY/BLK WIRE
HEADLAMP SWITCH
INADVERTANT PWR SUPPLY
LEFT FRONT DOOR COURTESY LAMP
LEFT LIFTGATE AJAR SWITCH RIGHT LIFTGATE AJAR SWITCH
LIFTGATE AJAR SIG RR DOOR AJAR SIG LR DOOR AJAR SIG
LIFTGLASS AJAR SWITCH
LOW REF
LR DOOR COURTESY LAMP (2003)
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MINI WEDGE (DRIVER DOOR JAMB SWITCH)
MINI WEDGE (LR DOOR JAMB SWITCH)
MINI WEDGE (RR DOOR JAMB SWITCH)
ORG/ WIRE
PNK/BLK WIRE
PPL INT LAMP DEFEAT SIG
PPL INT LAMP DEFEAT SW
RIGHT CARGO DOOR AJAR SWITCH
RIGHT CARGO DOOR CONTACT PLATE
RR DOOR COURTESY LAMP (2003)
SPLICE PACK
TAN WIRE
W/O CARGO DOORS W/ CARGO DOORS
Go to component -> Courtesy lamps circuit (1 of 3) -> LIFTGATE AJAR SIG RR DOOR AJAR SIG LR DOOR AJAR SIG
