Chevrolet Tahoe II (1999-2006) compressor/ leveling module Wiring diagram

5 VOLT REF RELAY CONTROL 7 3 BATT+ STEERING POST SIG A AUTOMATIC LEVEL CONTROL (ALC) COMPRESSOR RELAY (NEAR UNDERHOOD FUSE BLOCK) AVALANCHE/ ESCALADE EXT BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE COMPRESSOR MOTOR COMPRESSOR/ LEVELING MODULE COMPUTER DATA LINES SYSTEM CRUISE FUSE DATA LINES DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE EXCEPT ALL ESCALADE EXT OTHERS EXCEPT AVALANCHE/ ESCALADE EXT EXHAUST SOL GROUND GRY WIRE HOT AT ALL TIMES HOT IN IGN 3 FUSE LEFT FRONT SUSPENSION DAMPER SOLENOID LEFT I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LEFT REAR SUSPENSION DAMPER SOLENOID LF DAMP SERVO RR DAMP SERVO STEERING MARKER SIG LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE ORG/ WIRE PNK WIRE PNK/WHT WIRE POWERTRAIN CONTROL MODULE (PCM) (AT LEFT FRONT OF ENGINE COMPT) PPL/WHT WIRE PRESSURE SENSOR RED WIRE RED/BLK WIRE RIGHT FRONT SUSPENSION DAMPER SOLENOID RIGHT REAR SUSPENSION DAMPER SOLENOID RIGHT REAR SUSPENSION POSITION SENSOR (RIGHT REAR FRAME RAIL) RTD FUSE RUN WIRE SENSOR SIGNAL SPLICE PACK STEERING MARKER SIG STEERING POST SIG B STEERING POST SIG B SOLENOID CONTROL STEERING POST SIG A STUD 1 FUSE TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPT, NEAR BATTERY) WHT WIRE
