Transfer case circuit, without electronic shift control for Chevrolet Tahoe I (1995-1999)
Transfer case circuit, without electronic shift control
5 CM FROM TRANSFER CASE BREAKOUT)
A/T
BLK WIRE
BLK/WHT WIRE
BRN WIRE
DIESEL
FROM ENGINE HARN BREAKOUT)
FRONT AXLE ACTUATOR (RIGHT REAR OF FRONT DRIVE AXLE)
FRONT AXLE SWITCH (RIGHT REAR OF FRONT DRIVE AXLE)
FUSE 24
GASOLINE
GRY WIRE
GRY/BLK WIRE
HOT IN RUN
HOT WITH HEADLAMP SW IN PARK OR HEAD
I/P FUSE BLOCK (LEFT SIDE OF DASH,
ILLUM FUSE 14
INDICATOR
LT BLU WIRE
POWERTRAIN CONTROL MODULE (DIESEL)
RED WIRE
SPARE POWER SOURCE AUXILIARY BATTERY RELAY (EXC DIESEL)
TRANSFER CASE MODE SELECTOR ILLUMINATION LAMP
TRANSFER CASE RELAY
TRANSFER CASE SWITCH (TOP LEFT OF TRANSFER CASE)
TRANSFER CASE SYNCHRONIZER
