6.5l (vin s), cruise control circuit for Chevrolet Tahoe I (1995-1999)
6.5l (vin s), cruise control circuit
A/T OR
A/T PPL PPL PPL PPL M/T
BLK WIRE
BLU WIRE
BRAKE APPLIED INPUT
BRAKE FUSE 18 STOP/HAZ FUSE 1
BRN WIRE
BRN/WHT WIRE
CLUTCH PEDAL SWITCH (TOP OF CLUTCH PEDAL)
CRUISE FUSE 6
CRUISE ON INPUT
DISENGAGE INPUT
DK BLU WIRE
FUSE BLOCK
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN
M/T
MULTIFUNCTION LEVER
OFF
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (BEHIND CENTER OF I/P)
PPL
R/A
RESUME/ACCEL INPUT
S/C DK
SET/COAST INPUT
TCC/STOPLAMP SWITCH (TOP OF BRAKE PEDAL)
VEHICLE SPEED SENSOR (VSS) (LEFT SIDE OF TRANSMISSION)
VSS RETURN
WHT WIRE
