Chevrolet Tahoe I (1995-1999) left outside power rearview mirror Wiring diagram
This page shows the only wiring diagram for the component.left outside power rearview mirror, which is found in the car Chevrolet Tahoe I (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left outside power rearview mirror (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CONVENIENCE CENTER (BEHIND LEFT SIDE OF I/P)
CTSY FUSE 3
DOWN
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
ILLUM- NATION LAMP
LEFT
LEFT OUTSIDE POWER REARVIEW MIRROR
LEFT/ RIGHT MOTOR
LT GRN WIRE
ORG/ WIRE
POWER OUTSIDE REARVIEW MIRROR SWITCH
PPL/WHT WIRE
RED WIRE
RIGHT
RIGHT OUTSIDE POWER REARVIEW MIRROR
UP/ DOWN MOTOR
YEL WIRE
Go to component -> Power mirror circuit -> LEFT OUTSIDE POWER REARVIEW MIRROR
