Chevrolet Tahoe I (1995-1999) instru- ment cluster safety belts indicator Wiring diagram
This page shows the only wiring diagram for the component.instru- ment cluster safety belts indicator, which is found in the car Chevrolet Tahoe I (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instru- ment cluster safety belts indicator (1 of 1)
AUDIO ALARM MODULE (IN CONVENIENCE CENTER)
BLK WIRE
BLK/WHT WIRE
CONVENIENCE CENTER (UNDER LEFT SIDE OF I/P)
DIESEL
EX DIESEL
GAUGES FUSE 4
GRY WIRE
HOT AT ALL TIMES
HOT IN PARK OR HEAD
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
ILLUM FUSE 14
INSTRU- MENT CLUSTER SAFETY BELTS INDICATOR
KEY-IN WARNING BUZZER SWITCH
LEFT DOOR JAMB SWITCH
LIGHTS ON INPUT BATTERY INPUT KEY-IN WARNING
LT GRN WIRE
ORG/ WIRE
PNK IGN ON WIRE
PNK WIRE
SEAT BELT INPUT GROUND FASTEN BELTS OUT
SEAT BELT SWITCH (IN DRIVER'S SAFETY BELT BUCKLE)
STOP/HAZ FUSE 1
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
YEL WIRE
Go to component -> Warning system circuits -> INSTRU- MENT CLUSTER SAFETY BELTS INDICATOR
