Chevrolet Suburban XIII (2020-2024) primary fuel level sensor signal wiring diagram

3.0L TURBO DIESEL 5.3L, 6.2L AMBIENT AIR TEMPERATURE SENSOR AMBIENT AIR TEMPERATURE SENSOR SIGNAL AUTOSAR CAN BUS (-) 2 SER DATA BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRAKE FLUID LEVEL INDICATOR SWITCH BRN/BLU WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) ENGINE CONTROL SENSOR LOW REFERENCE 1 ENGINE CONTROL VEHICLE SENSORS 5 VOLT REFERENCE 1 ENGINE CONTROL VEHICLE SENSORS LOW REFERENCE 1 ENGINE CONTROLS SYSTEM ENGINE OIL LEVEL INDICATOR SWITCH ENGINE OIL PRESSURE SENSOR ENGINE OIL TEMPERATURE SENSOR FUEL LEVEL SENSOR FUEL LEVEL SENSOR LOW REFERENCE FUEL PUMP POWER CONTROL MODULE GMC/ CHEVROLET GRN/GRY WIRE GRN/YEL WIRE HOT AT ALL TIMES J134 (CADILLAC 3.0L TURBO DIESEL) J131 (CADILLAC 6.2L) J135 (CADILLAC 3.0L TURBO DIESEL) J131 (CADILLAC 6.2L) J184 (GMC, CHEVROLET 3.0L TURBO DIESEL) J151 (GMC, CHEVROLET 5.3L, 6.2L) J187 (GMC, CHEVROLET 3.0L TURBO DIESEL) J151 (GMC, CHEVROLET 5.3L, 6.2L) LEFT RIGHT LOGIC NCA WIRE OIL LEVEL SWITCH SIGNAL OIL PRESSURE SENSOR SIGNAL OIL TEMPERATURE SENSOR SIGNAL PARKING BRAKE CONTROL SWITCH PARKING BRAKE SWITCH POWER DISTRIBUTION SYSTEM PRIMARY FUEL LEVEL SENSOR SIGNAL PRIVATE SERIAL DATA POWERTRAIN CAN BUS (+) SERIAL DATA RED/GRN WIRE RIGHT END OF DASH) RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK SEEK DOWN SEEK UP SEL STEERING WHEEL RADIO CONTROL SWITCH TRANSFER CASE FLUID TEMPERATURE SENSOR SIGNAL VIO WIRE WHT WIRE WHT/RED WIRE YEL/BRN WIRE
