Chevrolet Suburban XIII (2020-2024) engine controls vehicle sensors 5 volt ref 1 Wiring diagram

3.0L TURBO DIESEL 6.2L, 5.3L AUTOMATIC TRANSMISSION ASSEMBLY AUTOSAR CAN BUS (+) 2 SERIAL DATA AUTOSAR CAN BUS (-) 2 SERIAL DATA BRK POS SENS SIG BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/YEL WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH) BODY CONTROL MODULE LIN BUS 1 BODY CONTROL MODULE LIN BUS 2 BRAKE PEDAL POSITION SENSOR BRK APPLY SENS CONTROL BRK APPLY SENS LOW REF BRK APPLY SENS SIG BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE ENGINE CONTROLS VEHICLE SENSORS 5 VOLT REF 1 ETRS OUT OF PARK SWITCH 2 SIGNAL ETRS OUT OF PARK SWITCH SIGNAL GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GROUND HIGH SPEED GMLAN SERIAL DATA (-) (1) HOT AT ALL TIMES LOW REF NCA WIRE ORG/ WIRE PARK LOCK SOLENOID CONTROL RED/BLU WIRE RIGHT END OF DASH) RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK TRANSMISSION CONTROL MODULE TRANSMISSION HIGH SIDE DRIVER 2 SIGNAL TRANSMISSION PARK VALVE LOCK SOLENOID ACTUATOR TRANSMISSION PARK VALVE POSITION SWITCH TRANSMISSIONS SYSTEM VIO/WHT WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE
