Chevrolet Suburban XIII (2020-2024) ctrl mod brake sys Wiring diagram
This page shows the only wiring diagram for the component.ctrl mod brake sys, which is found in the car Chevrolet Suburban XIII (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ctrl mod brake sys (1 of 1)
ANTI-LOCK BRAKES SYSTEM
APPLY SIG TRAILER BRK
AUX CTRL TRLR
AUX PARK LP RLY CTRL
BACKUP LP RLY CTRL
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRY WIRE
CAN BUS- GND
CAN-BUS
COMPUTER DATA LINES SYSTEM
CTRL MOD BRAKE SYS
ENABLE SIG TRAILER BRK
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
LEFT TRAILER STOP/ TURN SIGNAL LAMP RELAY
LIGHTING CONTROL MODULE (UNDER LEFT END OF DASH)
LIN BUS 2
LR TRAILER STP/TN LP CTRL RR TRAILER STP/TN LP CTRL
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT TRAILER STOP/ TURN SIGNAL LAMP RELAY
TOW VEHICLE ELECTRICAL RECEPTACLE
TRAILER BACKUP LAMP RELAY
TRAILER BRAKE CONTROL MODULE (UNDER VEHICLE, NEAR SPARE TIRE)
TRAILER BRAKES PROVISION BLUNT CUT (IF EQUIPPED) (UNDER LEFT SIDE OF DASH)
TRAILER PARKING LAMP RELAY
VIO WIRE
VIO/BLK WIRE
VIO/WHT WIRE
VOLT BATT POS
W/ TRAILER INFORMATION INDICATOR
W/O INTEGRATED TRAILER BRAKE
W/O TRAILER INFORMATION INDICATOR
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Trailer tow circuit (1 of 2) -> CTRL MOD BRAKE SYS
