Chevrolet Suburban XIII (2020-2024) automatic transmission intermediate speed sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.automatic transmission intermediate speed sensor 2, which is found in the car Chevrolet Suburban XIII (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic transmission intermediate speed sensor 2 (1 of 1)
ADAPTIVE CRUISE SWITCH
AUTOMATIC TRANSMISSION ASSEMBLY
AUTOMATIC TRANSMISSION INPUT SPEED SENSOR
AUTOMATIC TRANSMISSION INTERMEDIATE SPEED SENSOR 1
AUTOMATIC TRANSMISSION INTERMEDIATE SPEED SENSOR 2
AUTOMATIC TRANSMISSION OUTPUT SPEED SENSOR
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRN/BLU WIRE
BRN/GRN WIRE
CANCEL SWITCH
COLLISION ALERT WARNING SWITCH FORWARD
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
CRUISE IND
CRUISE SWITCH
DISPLAY
GAP SWITCH
GRN WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
INPUT SPD SIG
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LO SPD GMLAN SERIAL DATA 2
LOGIC
MULTI-FUNCTION POWER SUPPLY CONVERTER
NCA WIRE
OUTPUT SPD SIG
RED/GRN WIRE
RED/YEL WIRE
RES+
RIGHT END OF DASH)
RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
SET-
STEERING WHEEL AIR BAG COIL
TRANS INPUT SPD SIG HIGH
TRANS INTERMEDIATE SPD SIG
TRANSMISSION CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
TRANSMISSIONS SYSTEM
VIO/GRN WIRE
W/ ADAPTIVE CRUISE CONTROL
W/O ADAPTIVE CRUISE CONTROL
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Cruise control circuit (3 of 3) -> AUTOMATIC TRANSMISSION INTERMEDIATE SPEED SENSOR 2
