Passenger power seat circuit, 6-way power seat for Chevrolet Suburban XI (2007-2013)

Passenger power seat circuit, 6-way power seat

Get access

BLK WIRE DK BLU WIRE DK GRN WIRE DOWN HOT AT ALL TIMES LEFT I/P JUNCTION BLOCK (LEFT END OF DASH) LT BLU WIRE LT GRN WIRE NCA WIRE PASS SEAT 1 CIRCUIT BREAKER PASSENGER SEAT ADJUSTER ASSEMBLY (UNDER FRONT PASSENGER'S SEAT) PASSENGER SEAT ADJUSTER SWITCH PASSENGER SEAT FRONT VERTICAL MOTOR PASSENGER SEAT HORIZONTAL MOTOR PASSENGER SEAT REAR VERTICAL MOTOR RED/WHT WIRE RWD TAN WIRE YEL WIRE
