Chevrolet Suburban XI (2007-2013) s/roof fuse 33 Wiring diagram

This page shows the only wiring diagram for the component.s/roof fuse 33, which is found in the car Chevrolet Suburban XI (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram s/roof fuse 33

Wiring diagram s/roof fuse 33 for Chevrolet Suburban XI (2007-2013)

Get access

BLK WIRE BRN/WHT WIRE DK GRN WIRE GROUND DISTRIBUTION SYSTEM RIGHT I/P JUNCTION BLOCK (RIGHT END OF DASH) HOT AT ALL TIMES I/P LEFT I/P JUNCTION BLOCK (LEFT END OF DASH) PDM FUSE FUSE BLOCK (LEFT END OF DASH) POLICE PROVISION (BLUNT CUT) POWER DISTRIBUTION SYSTEM RED/WHT WIRE RIGHT I/P JUNCTION BLOCK (RIGHT END OF DASH) ROOF BEACON RELAY (IN OVERHEAD CONSOLE) ROOF BEACON SWITCH S/ROOF FUSE 33 UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE

Go to component: Exterior lights -> Beacon lamp circuit -> S/ROOF FUSE 33
