Chevrolet Suburban XI (2007-2013) release ctrl 2 b+ ground ajar sw sig release ctrl sw sig Wiring diagram

11 3 L/GATE SIG L/GLASS SIG 1303 2279 PPL BLK WIRE BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH) CADILLAC GMC/CHEVROLET DK GRN/WHT WIRE GMC, CHEVROLET, CADILLAC EXCEPT GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES I/P FUSE REAR WPR FUSE BLOCK (LEFT END OF DASH) L/GATE CNTRL L/GATE SIG LIFTGATE LATCH ASSEMBLY (CENTER OF LIFTGATE) LIFTGATE WINDOW LATCH ASSEMBLY LOGIC REAR WINDOW WIPER MOTOR (CENTER OF LIFTGATE) LT BLU WIRE LT GRN WIRE NCA WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM POWER LIFTGATE MODULE (LEFT REAR OF CARGO AREA) PPL REAR WASH FUSE 23 REAR WASH PCB RELAY REAR WINDOW WASHER FLUID PUMP (WASHER FLUID RESERVOIR) RED/WHT WIRE RELEASE CTRL 2 B+ GROUND AJAR SW SIG RELEASE CTRL SW SIG RR WPR VOLT TAN WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) W/O POWER LIFTGATE W/ POWER LIFTGATE CADILLAC HYBRID WHT WIRE
