Chevrolet Suburban XI (2007-2013) passenger seat lumbar vertical motor Wiring diagram

This page shows the only wiring diagram for the component.passenger seat lumbar vertical motor, which is found in the car Chevrolet Suburban XI (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger seat lumbar vertical motor

Wiring diagram passenger seat lumbar vertical motor for Chevrolet Suburban XI (2007-2013)

Get access

BLK WIRE DK BLU WIRE DK GRN WIRE HOT AT ALL TIMES LEFT I/P JUNCTION BLOCK (LEFT END OF DASH) LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE OUT PASS SEAT 1 CIRCUIT BREAKER PASSENGER SEAT ADJUSTER ASSEMBLY (UNDER FRONT PASSENGER'S SEAT) PASSENGER SEAT ADJUSTER SWITCH PASSENGER SEAT FRONT VERTICAL MOTOR PASSENGER SEAT HORIZONTAL MOTOR PASSENGER SEAT LUMBAR HORIZONTAL MOTOR PASSENGER SEAT LUMBAR SWITCH PASSENGER SEAT LUMBAR VERTICAL MOTOR PASSENGER SEAT REAR VERTICAL MOTOR PASSENGER SEAT RECLINE MOTOR (UNDER FRONT PASSENGER'S SEAT) PNK WIRE RED/WHT WIRE RWD TAN WIRE WHT WIRE YEL WIRE

Go to component: Power seats -> Passenger power seat circuit, 8-way power seat -> PASSENGER SEAT LUMBAR VERTICAL MOTOR
