Chevrolet Suburban XI (2007-2013) passenger inflatable restraint seat position sensor Wiring diagram

1 1 RH ROOF RAIL MOD HIGH CTRL RH ROOF RAIL MOD LOW CTRL 13-14, 15-16, 17-18, 37-38, 39-40, 53-54) BLK/WHT WIRE DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE GRY WIRE GRY/BLK WIRE INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER DRIVER'S SEAT) LEFT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE MANUAL LIFT GATE W/ LIFT GLASS MANUAL LIFT GATE W/O LIFT GLASS NCA WIRE ORG/ WIRE PASSENGER INFLATABLE RESTRAINT SEAT POSITION SENSOR PASSENGER SEAT BELT SWITCH PIN SHORTING BARS ENGAGED WHEN MODULE CONNECTOR IS DISCONNECTED FROM HARNESS: PNK WIRE PNK/BLK WIRE PPL PPL/WHT WIRE RIGHT FRONT INFLATABLE RESTRAINT ROOF RAIL MODULE (TOP OF RIGHT "C" PILLAR) RIGHT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE SHORTING BAR TAN/BLK WIRE TAN/ORG WIRE TAN/WHT WIRE W/ NON-BUCKET INDIVIDUAL WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
